Remote Operations
Codes and Actions 4
4-5
Lionheart 3. Both active and inactive numeric-control codes are listed; when operating in
the numeric-control mode, selecting DOWN or UP on the LCD screen automatically
skips the inactive codes.
For more information about using the remote-control-entry codes (including how to use
one specific remote-control command to operate the MPS450 in the numeric-control
mode), see the “Remote Operations” section.
ECG Functions
The ECG functions category consist of Normal-Sinus ECG, ECG Amplitude,
Adult/Pediatric, STE Elevation, ECG Artifact simulation, Pacemaker Waveform,
Pacemaker Amplitude, and Pacemaker Width
Normal-Sinus ECG
Table 4-3 lists the numeric control codes for the normal-sinus ECG functions.
Table 4-3. Numeric Codes for Normal Sinus ECG Actions
Numeric
Control Code
Action
Remote Control
Entry
165 Run normal sinus ECG at 30 BPM. NSR30
166 Run normal sinus ECG at 40 BPM. NSR40
250 Run normal sinus ECG at 45 BPM. NSR45
167 Run normal sinus ECG at 60 BPM. NSR60
168 Run normal sinus ECG at 80 BPM. NSR80
251 Run normal sinus ECG at 90 BPM. NSR90
169 Run normal sinus ECG at 100 BPM. NSR100
170 Run normal sinus ECG at 120 BPM. NSR120
171 Run normal sinus ECG at 140 BPM. NSR140
172 Run normal sinus ECG at 160 BPM. NSR160
173 Run normal sinus ECG at 180 BPM. NSR180
174 Run normal sinus ECG at 200 BPM. NSR200
175 Run normal sinus ECG at 220 BPM. NSR220
176 Run normal sinus ECG at 240 BPM. NSR240
177 Run normal sinus ECG at 260 BPM. NSR260
178 Run normal sinus ECG at 280 BPM. NSR280
179 Run normal sinus ECG at 300 BPM. NSR300
ECG Amplitude
Table 4-4 lists the numeric control codes for the ECG amplitude functions.
Table 4-4. Numeric Codes for ECG Amplitude Actions
Numeric
Control Code
Action
Remote Control
Entry
252 Set ECG amplitude to 0.05 mV. NSA0.05
