Fluke Biomedical MPS450 - R-Wave Amplitude

Remote Operations
Codes and Actions 4
4-13
Table 4-18. Numeric Codes for R-Wave Width Actions (cont.)
Numeric
Control Code
Action
Remote Control
Entry
323 Set R-wave width to 40 ms RWW40
324 Set R-wave width to 50 ms RWW50
325 Set R-wave width to 60 ms RWW60
326 Set R-wave width to 70 ms RWW70
327 Set R-wave width to 80 ms RWW80
328 Set R-wave width to 90 ms RWW90
329 Set R-wave width to 100 ms RWW100
330 Set R-wave width to 110 ms RWW110
331 Set R-wave width to 120 ms RWW120
332 Set R-wave width to 130 ms. RWW130
333 Set R-wave width to 140 ms. RWW140
334 Set R-wave width to 150 ms. RWW150
335 Set R-wave width to 160 ms. RWW160
336 Set R-wave width to 170 ms. RWW170
337 Set R-wave width to 180 ms. RWW180
338 Set R-wave width to 190 ms. RWW190
339 Set R wave width to 200 ms. RWW200
R-Wave Amplitude
Table 4-19 lists the numeric control codes for the R-wave amplitude functions.
Table 4-19. Numeric Codes for R-Wave Amplitude Actions
Numeric
Control Code
Action
Remote Control
Entry
292 Set R-wave amplitude to 0.05 mV. RWA0.05
293 Set R-wave amplitude to 0.15 mV. RWA0.10
294 Set R-wave amplitude to 0.15 mV. RWA0.15
295 Set R-wave amplitude to 0.05 mV. RWA0.20
296 Set R-wave amplitude to 0.25 mV. RWA0.25
297 Set R-wave amplitude to 0.05 mV. RWA0.30
298 Set R-wave amplitude to 0.35 mV. RWA0.35
299 Set R-wave amplitude to 0.05 mV. RWA0.40
300 Set R-wave amplitude to 0.45 mV. RWA0.45
301 Set R-wave amplitude to 0.05 mV. RWA0.50
