Fluke Biomedical MPS450 - ECG Artifact Stimulation

Remote Operations
Codes and Actions 4
4-7
Table 4-6. Numeric Codes for STE Elevation Action (cont.)
Numeric
Control Code
Action
Remote Control
Entry
236 Set ST elevation to -0.7 mV. STD-0.7
235 Set ST elevation to -0.6 mV. STD-0.6
234 Set ST elevation to -0.5 mV. STD-0.5
233 Set ST elevation to -0.4 mV. STD-0.4
232 Set ST elevation to -0.3 mV. STD-0.3
231 Set ST elevation to -0.2 mV. STD-0.2
230 Set ST elevation to -0.1 mV. STD-0.1
221 Set ST elevation to -0.05 mV. STD-0.05
220 Set ST elevation to 0. STD0
219 Set ST elevation to +0.05 mV. STD+0.05
229 Set ST elevation to +0.1 mV. STD+0.1
228 Set ST elevation to +0.2 mV. STD+0.2
227 Set ST elevation to +0.3 mV. STD+0.3
226 Set ST elevation to +0.4 mV. STD+0.4
225 Set ST elevation to +0.5 mV. STD+0.5
224 Set ST elevation to +0.6 mV. STD+0.6
223 Set ST elevation to +0.7 mV. STD+0.7
222 Set ST elevation to +0.8 mV. STD+0.8
ECG Artifact Stimulation
Table 4-7 lists the numeric control codes for the ECG artifact Stimulation functions.
Table 4-7. Numeric Codes for ECG Artifact Stimulation Actions
Numeric
Control Code
Action
Remote Control
Entry
104 Set ECG artifact to off. EAOFF
105 Set ECG artifact to 50 Hz sine. EA50
106 Set ECG artifact to 60 Hz sine. EA60
107 Set ECG artifact to muscle. EAMSC
108 Set ECG artifact to wandering baseline. EAWNDR
109 Set ECG artifact to respiration. EARESP
