Maintenance and Specifications
Specifications
8
8-11
Test Standards
Note
Refer to the test standards document included on the CableManager
CD for more details on test standards.
Test Standard Link Type
TIA Category 3 and 5E per Addendum #5
to TIA/EIA-568A
basic link or channel
TIA Category 5 (new) per TIA TSB-95 basic link or channel
TIA Category 6 per TIA Addendum #1
to TIA/EIA-568B (draft)
permanent link or channel
ISO/IEC-11801-2000 Class C and D (new) permanent link or channel
ISO/IEC-11801-2000+ Class E (draft) permanent link or channel
STP cabling, (IBM Type 1, 150 Ω)
ANSI TP-PMD
IEEE 802.3 10BASE5, 10BASE2
Ethernet with coaxial cabling
IEEE 802.3 10BASE-T, 100BASE-TX, 1000BASE-T Ethernet with twisted pair cabling
IEEE 802.5 Token Ring, 4 Mb/s or 16 Mb/s
Additional test standards are available. For information on additional test
standards, testing to higher cabling performance standards or different cabling
types (including fiber optic cabling) contact Fluke Networks.
Fiber optic test standards are supported when using the optional Fiber Test
Adapters. See those products’ manuals for more information.
Time for Autotest
Full 2-way Autotest of Category 5 UTP cable in approximately 10 seconds.
