DSP-4000 Series
Users Manual
2-20
Remote Features
Figure 2-8 shows the features on the remote unit, and Table 2-5 explains their
functions.
ON
OFF
PASS
TESTING
TALKING
FAIL
LOW BATTERY
TALK
1
2
3
5
6
7
8
9
10
11
12
4
oy06f.eps
Figure 2-8. Remote Features
