Section III - Dynamic Displays
MN06065 Rev. 0.3 (8/97) 19
Dynamic Display Reference (Products)
00 - Temperature
The current temperature of the product requested
being measured and used for compensation will be
displayed.
Temperature = + 78.5°F
01 - API
The current API of the product requested being used
for compensation will be displayed.
API = + 19.9
02 - Product Flow Rate (Units/Min)
The product's current flow rate in units per minute
will be displayed.
Flow Hi = 500.0 Gal/Min
Where: Hi = High Flow
Lo = Low Flow
Mn = Minimum Flow
Q1 = Step 1 of shut-down
Q2 = Step 2 of shut-down
Q3 = Step 3 of shut-down
ST = Not Flowing
Note:
+ or - means that the flow rate has been adjusted upward (+)
or downward (-).
03 - Product Flow Rate (Units/Hour)
The product's current flow rate in units per hour will
be displayed.
Flow Hi = 30000 Gal/Hr
Where: Hi = High Flow
Lo = Low Flow
Mn = Minimum Flow
Q1 = Step 1 of shut-down
Q2 = Step 2 of shut-down
Q3 = Step 3 of shut-down
ST = Not Flowing
Note:
+ or - means that the flow rate has been adjusted upward (+)
or downward (-).
04 - Reference Density
The current reference density of the product re-
quested being used will be displayed.
Ref Density = 933.7 Kg/M3
05 - Relative Density
The current relative density of the product requested
being used will be displayed.
Rel Density = 0.09346
06 - Density
The current density of the product requested being
used will be displayed.
Density N/A
07 - Pressure and Vapor Pressure
If used, the current pressure and vapor pressure of
the product requested will be displayed.
P = 45.0 VP = 10.0
To Next Page
