FMC Technologies Smith Meter AccuLoad II User Manual

Section V - Program Codes
MN06065 Rev. 0.3 (8/97) 43
System Configuration Directory
Code Description
000 System Configuration Directory
001 Number of Products
002 Number of Additive Injectors
003 A/C Output Relay 1 Terminals 89 & 90
004 A/C Output Relay 2 Terminals 91 & 92
005 A/C Output Relay 3 Terminals 93 & 94
006 A/C Output Relay 4 Terminals 95 & 96
007 A/C Output Relay 5 Terminals 87 & 88
008 A/C Output Relay 6 Terminals 84 & 85
009 A/C Output Relay 7 Terminals 124 & 125
010 A/C Output Relay 8 Terminals 126 & 127
011 A/C Output Relay 9 Terminals 128 & 129
012 A/C Output Relay 10 Terminals 130 & 131
013 A/C Output Relay 11 Terminals 121 & 122
014 A/C Output Relay 12 Terminals 119 & 120
015
D/C Output Relay 1 Terminals 9 & 10 (w/o Quad OPV), Terminals 11 & 10
(on/Quad OPV)
016
D/C Output Relay 2 Terminals 57 & 58 (on Quad OPV), Terminals 15 & 14
(on/Quad OPV)
017 D/C Output Relay 3 Terminals 13 & 12 on Quad OPV
018 D/C Output Relay 4 Terminals 17 & 16 on Quad OPV
019 A/C Input 1 Terminals 98 & 101
020 A/C Input 2 Terminals 99 & 101
021 A/C Input 3 Terminals 100 & 101
022 A/C Input 4 Terminals 103 & 105
023 A/C Input 5 Terminals 104 & 105
024 A/C Input 6 Terminals 73 & 74
025 A/C Input 7 Terminals 106 & 109
026 A/C Input 8 Terminals 107 & 109
027 A/C Input 9 Terminals 108 & 109
