Section V - Program Codes
44 MN06065 Rev. 0.3 (8/97)
Code Description
028 A/C Input 10 Terminals 110 & 112
029 A/C Input 11 Terminals 111 & 112
030 A/C Input 12 Terminals 75 & 76
031 RTD #1 Terminals 14, 15, 16, & 17
032 RTD #2 Terminals 62, 63, 64 & 65
033 4-20 Channel #1 Terminals 19 & 20
034 4-20 Channel #2 Terminals 22 & 23
035 4-20 Channel #3 Terminals 68 & 69
036 4-20 Channel #4 Terminals 71 & 72
037 Additive Injector #1 Plumbing
038 Additive Injector #2 Plumbing
039 Additive Injector #3 Plumbing
040 Additive Injector #4 Plumbing
041 Additive Injector #5 Plumbing
042 Additive Injector #6 Plumbing
043 Additive Injector #7 Plumbing
044 Additive Injector #8 Plumbing
045-089 Unassigned at Present
090 Program the Input/Output Configuration
091 Print Configuration
092-099 Unassigned at Present
100 System General Purpose Directory
101 System Alarm Check/Reset
102 Product 1 Alarm Check/Reset
103 Product 2 Alarm Check/Reset
104 Product 3 Alarm Check/Reset
105 Product 4 Alarm Check/Reset
106 Recipe Alarms Check/Reset
107 Transaction Alarms
108 Ready Mode Alarms
109 Set Time
