Section III - Dynamic Displays
MN06065 Rev. 0.3 (8/97) 21
18 - Load Average Density
The load average density of the product requested
for the current transaction will be displayed.
Ld Avg Den N/A
19 - Load Average Meter Factor
The load average meter factor of the product re-
quested for the current transaction will be displayed.
Load Avg Mfac = 0.9998
20 - Raw Volume
The raw transaction volume that is currently being
loaded of the product requested will be displayed.
Raw Transaction 192.75
21 - Gross Volume
The gross volume that is currently being loaded of
the product requested will be displayed.
Grs Transaction 200.00
22 - Gross @ Standard Temperature Volume
The gross @ standard temperature compensated
volume that is currently being loaded of the product
requested will be displayed.
Gst Transaction 198.54
23 - Net Transaction
The net volume that is currently being loaded of the
product requested will be displayed.
Net Transaction 200.72
24 - Mass Transaction
The mass that is currently being loaded of the prod-
uct requested will be displayed.
Mas Transaction N/A
25 - Valve Position
The status of the current valve position will be dis-
played.
Valve Requested Open
26 - Current Blend Ratio
The current blend ratio of the product requested will
be displayed.
Current 24.9% of Batch
27 - Desired Blend Ratio
The desired blend ratio of the product requested will
be displayed.
Desired 25.0% of Batch
