Section III - Dynamic Displays
16 MN06065 Rev. 0.3 (8/97)
Dynamic Display Reference (System)
00 - Time & Date
The current time and date will be displayed.
9:20:05 AM 10-10-92
01 - System Flow Rate (Units/Min)
The current system flow rate of the recipe requested
in units per minute will be displayed.
Note:
An "*" in front of the flow rate indicates the flow is being con-
trolled lower than selected because back pressure or auto flow
control is not sufficient to maintain the desired flow.
Flow = 1000.0 Gal/Min
Note:
+ or - means that the flow rate has been adjusted upward (+)
or downward (-).
02 - System Flow Rate (Units/Hr)
The current system flow rate of the recipe requested
in units per hour will be displayed.
Note:
An "*" in front of the flow rate indicates the flow is being con-
trolled lower than selected because back pressure or auto flow
control is not sufficient to maintain the desired flow.
Flow = 60000.0 Gal/Hr
Note:
+ or - means that the flow rate has been adjusted upward (+)
or downward (-).
03 - Current Recipe
The recipe that is currently being loaded will be dis-
played:
Current Recipe=Midgrade
04 - Current Products
The products that are currently being loaded will be
displayed.
Current Products 1 2 3 4
05 - Injector #1 Volume
The additive injector #1 non-resettable totals will be
displayed.
Add 1 = 0000121555 Oz
06 - Injector #2 Volume
The additive injector #2 non-resettable totals will be
displayed.
Add 2 = 0000024260 Oz
07 - Injector #3 Volume
The additive injector #3 non-resettable totals will be
displayed.
Add 3 = 000004590 Oz
08 - Injector #4 Volume
The additive injector #4 non-resettable totals will be
displayed.
Add 4 = 000005540 Oz
