FMC Technologies Smith Meter AccuLoad II User Manual

Section III - Dynamic Displays
MN06065 Rev. 0.3 (8/97) 29
21 - Additive Injector 2 Transaction Volume
The total for additive injector 2 for the last transac-
tion will be displayed.
Injector 2 350.00 Oz
22 - Additive Injector 3 Transaction Volume
The total for additive injector 3 for the last transac-
tion will be displayed.
Injector 3 455.00 Oz
23 - Additive Injector 4 Transaction Volume
The total for additive injector 4 for the last transac-
tion will be displayed.
Injector 4 350.000 Oz
24 - Additive Injector 5 Transaction Volume
The total for additive injector 5 for the last transac-
tion will be displayed.
Injector 5 0.000 Oz
25 - Additive Injector 6 Transaction Volume
The total for additive injector 6 for the last transac-
tion will be displayed.
Injector 6 0.000 Oz
26 - Additive Injector 7 Transaction Volume
The total for additive injector 7 for the last transac-
tion will be displayed.
Injector 7 0.000 Oz
27 - Additive Injector 8 Transaction Volume
The total for additive injector 8 for the last transac-
tion will be displayed.
Injector 8 0.000 Oz
28 - Raw Transaction Volume
The raw total for the first recipe of the transaction
will be displayed.
Raw Trans 500.77
Note:
If the same recipe is used more than once in a transaction,
the totals will be summed over the transaction. (This note applies to
all dynamic displays that follow (28 - ...).
29 - Gross Transaction Volume
The gross total of the last transaction will be dis-
played.
Grs Trans 500.41
30 - Gross at Standard Temperature
Transaction Volume
The gross at standard temperature total for the last
transaction will be displayed.
Gst Trans 499.42
