Folger Tech FT-5 - Page 42

FT-5 User Manual Page 41
11. Flip FT9 over and place a female cable mount
over the two holes. Secure it in place using
two M3x12mm screw and two M3 Nylock.
12. Remove two of the screws from the back of
the stepper motor.
13. Place FT9 over the back of the stepper motor.
Secure it in place using two M3x40mm screws.
