FOR-A MFR-3100EX - FS Mode

46
Item
Specifications
Window size
1/16, 1/9 or 1/4
Other MV objects
- Background (Input image, Matte or BLACK)
- Text (8 characters x 2)
- Window frame (normal or tally)
- Tally marker
- Audio level meter (8 channels)
- Timecode
- Video loss
Savable MV layouts
16 (16 per each MFR-3100EX unit)
Layout Manager
Screen and window layout creation and editing in Web-based Control
* Window and text locations are arbitrary.
Clock time
- Source: Internal clock source
- SNTP adjustment available
- Power source: Built-in lithium battery
Loop playback
Sequence display of input sources (up to 64 inputs) on a multiview
screen
Adjustable timing
-0.5H to +1.5H
* When using asynchronous input signals, select ON in FS Mode. Some functions are disabled when ON is
selected. See next section for details.
4-2. FS Mode
When using asynchronous input signals, select ON in the [Web-based Control: MV Settings > FS
Mode]. Setting FS Mode to ON disables or limits the following functions.
Item
FS Mode: ON
FS Mode: OFF (Default)
Time Code
Not displayed
Displayed
Background
Matte, BLACK
EXTERNAL, Matte, BLACK
In-Out Delay
1-2 frames
1 frame
Adjustment range
1 frame
2H adjustable
(-0.5H to +1.5H)
Multiviewer
1
2
