9. Specifications and Dimensions
9-1. Unit Specifications
9-1-1. MFR-3100EX
Basic specifications
Temperature/ Humidity
0℃ to 40℃/ 30% to 85% (no condensation)
Power
100VAC to 240VAC ±10%, 50/60Hz IN x 2
(MFR-31PS required for redundant power configuration)
Consumption
671VA (661W) at 100 - 120VAC
608VA (510W) at 220 - 240VAC
Dimensions
430 (W) x 177 (H) x 400 (D) mm EIA 4RU
482 (W) (including rack mount brackets)
Weight
25kg (with full options)
Technical specifications
Video Formats
UHD 4K
(12G-SDI)
(3G-SDI)
2160p / 59.94, 50 (With MFR-8SDIGB/ 8SDOGB)
Single Link 12G-SDI (SMPTE ST 2082-10)
Quad Link 3G-SDI (SMPTE ST 425-5)
HD (3G-SDI)
1080p / 60, 59.94, 50 (SMPTE 424M)
HD (HD-SDI)
1080i / 60, 59.94, 50
1080p / 30, 29.97, 23.98, 25, 24
1080PsF / 30, 29.97, 23.98, 25, 24
720p / 60, 59.94, 50 (SMPTE 292M)
SD (SD-SDI)
525/59.94i, 625/50i (SMPTE 259M) (With MFR-8SDI/ 8SDO)
DVB-ASI
Compliant to EN 50083-9 (MFR-8SDI/ 8SDO)
Matrix Size
Min. 8 x 8 to Max. 64 x 72 (Max. logical matrix: 512 x 512)
Number of input slots: 8
Number of output slots: 9
(Expandable on an 8-channel basis)
Video Input
MFR-8SDI
(as video input)
3G/HD/SD-SDI Input Card (Max. 8 cards)
- 75-ohm BNC x 8
Cable Equalization
3G/HD-SDI: 100 m (5C-FB cable)
SD-SDI: 200 m (5C-2V cable)
MFR-8SDIGB
12G/3G-SDI Input Card (Max. 8 cards)
- 75-ohm BNC x 2 (12G-SDI or 3G-SDI)
- 75-ohm BNC x 6 (3G-SDI)
I/O delay selection
Delay (H) (0.3H-1H), 1 frame, 1 frame+ Delay (H)
Cable Equalization
12G-SDI: 100 m (L-5.5CUHD cable)
3G-SDI: 100 m (5C-FB cable)
Video Output
MFR-8SDO
3G/HD/SD-SDI Output Card (Max. 9 cards)
- 75 ohm BNC x 8 (Auto reclocking)
