7-3-10. Audio Channel Mapping Command (14)
This command allows you to map audio channels on MFR-8MADIPO/8AESPO.
► [Web-based Control: Audio Settings - Audio Mapping page]
◆ Command Format
Command
@[sp]AX:<SlotNo.><Grp>/<O-BNC><O-CH>,<I-No><I-CH>
Command response
AC:<SlotNo.><Grp>/<O-BNC><O-CH>,<I-No><I-CH>:I<ID>
Parameter
<SlotNo.>
0-8
Slot9 to Slot17
<Grp>
0
0: Group1
<O-BNC>
0-7
Output channel (stream)
CH1 to CH8
<O-CH>
0-1F
Audio channel in the Output stream
CH1 to CH32
<I-No>
0-7
Input channel (stream)
CH1 to CH8
<I-CH>
0-1F,
FF
Audio channel in the Input stream
0-1F: CH1 to CH32
FF: Silence
<ID>
01-FF
Unit ID
◆ Command / Response Example
Assign CH 4 in Audio Input 3 (stream) to CH 17 in Group1 Audio Output 2 (on Slot 9).
Command
Parameter
Description
@ AX:
0
<SlotNo.>
Slot9
0
<Grp>
Group1
/
1
<O-BNC>
Audio output (stream) 2
10
<O-CH>
Output channel 17
,
2
<I-No>
Audio input (stream) 3
03
<I-CH>
Input Channel 4
Response
Description
AC:00/110,23:IA
Received mapping switch request from the unit ID10: Assign CH 4 in Audio
Input 3 (stream) to CH 17 in Group1 Audio Output 2 (on Slot 9).
