MFR-8SDOGB
12G/3G-SDI Output Card (Max. 9 cards))
-75 ohm BNC x 2 (12G-SDI or 3G-SDI )
-75 ohm BNC x 6 (3G-SDI)
I/O delay selection:
Delay (H) (0.3H-1H), 1 frame, 1 frame+ Delay (H)
MFR-8SDODL
3G/HD-SDI Output Card (Max. 9 cards)
-75 ohm BNC x 8
Phase adjustment for 3G/HD-SDI output
- Output phase: +1H to +5H referring to REF IN signal
- Adjustment range (variable depending on the output phase)
+1H output: -4.1H to +0.9H
+2H output: -3.1H to +1.9H
+3H output: -2.1H to +2.9H
+4H output: -1.1H to +3.9H
+5H output: -0.1H to +4.9H
- Quiet Switch OFF: Passes through all ANC data in inputs
(W/o measures for signal switching effects)
- Quiet Switch ON: Passes through ANC data below (reproduced)
- SMPTE ST352 (Video payload ID information)
- SMPTE ST299-1 (Embedded audio)
16-channel (Group1-4), PCM, 48kHz 24bit, Synchronous
Audio Input
MFR-8AAI
Analog Audio Input Card with A/D converter (Max. 8 cards)
- 25-pin D-sub (female) x 2 (8 stereo pairs, 16 channels)
- Balanced or unbalanced, 600-ohm or high impedance
- A/D conversion: 48kHz / 24bit
MFR-8AESI
AES/EBU Audio Input Card (Max. 8 cards)
- 75-ohm, BNC x 8 (8 stereo pairs, 16 channels)
- 48kHz / 24bit (No limitation for MFR-8AESO)
MFR-8SDI
(as audio input)
MADI Audio Input Card (Max. 8 cards)
- 75-ohm, BNC x 8 (MADI x 8)
- MADI: 64-channel, 48kHz / 24bit
Audio Output
MFR-8AAO
Analog Audio Output Card with D/A converter (Max. 9 cards)
- 25-pin D-sub (female) x 2 (8 stereo pairs. 16 channels),
- Balanced or unbalanced, 600-ohm or 100-ohm
- D/A conversion: 48kHz / 24bit
MFR-8AESO
AES/EBU Audio Output Card (Max. 9 cards)
- 75-ohm BNC x 8 (8 stereo pairs. 16 channels)
- 48kHz / 24bit (No limitation for MFR-8AESI)
MFR-8MADIPO
MADI/SDI Output Card (Max. 9 cards)
- 75-ohm BNC x 8 (MADI/SDI x 8)
Audio output
- MADI: 64-channel, 48kHz / 24bit (AES10-2008(MADI))
- Audio I/O delay: 1 ms or less
Video output:
- 3G-SDI: 1080p / 59.94, 50
- HD-SDI: 1080i / 59.94, 50
1080PsF / 29.97, 23.98
720p /59.94
- Additional delay time: Delay (H) (0.2H-1H)
MFR-8AESPO
AES/EBU Audio Output Card (Max. 9 cards)
- 75-ohm BNC x 8 (8 stereo pairs. 16 channels)
- 48kHz / 24bit
- Audio I/O delay: 1 ms or less
