FOR-A MFR-3100EX - Page 76

76
Parameter
<SlotNo.>
0-8
Slot9 to Slot17
<Grp>
0
0: Group1
<FORMAT>
00,
01,
04,
05,
07,
0F,
12
Video Format
00: 1080/59.94i
01: 1080/59.94p
04: 1080/50i
05: 1080/50p
07: 720/59.94p
0F: 1080/29.97PsF
12: 1080/23.98PsF
<D#>
D0-D8
Output delay
Pattern 1 to Pattern 9
* The output delay varies depending on the video format. (See table
below)
FORMAT
Output Delay [μs]
D0
D1
D2
D3
D4
D5
D6
D7
D8
00:1080/59.94i
5.93
8.90
11.86
14.83
17.80
20.76
23.73
26.69
29.66
01:1080/59.94p
2.97
4.45
5.93
7.41
8.90
10.38
11.86
13.35
14.83
04:1080/50i
7.11
10.67
14.22
17.78
21.33
24.89
28.44
32.00
35.56
05:1080/50p
3.56
5.33
7.11
8.89
10.67
12.44
14.22
16.00
17.78
07:720/59.94p
4.45
6.67
8.90
11.12
13.35
15.57
17.80
20.02
22.24
0F:1080/29.97PsF
5.93
8.90
11.86
14.83
17.80
20.76
23.73
26.69
29.66
12:1080/23.98PsF
7.41
11.12
14.83
18.54
22.24
25.95
29.66
33.37
37.07
◆ Command / Response Example
(1) Set the SDI output video format of Group1 in Slot13 to 1080/59.94p and Output Delay to
14.83μs (Pattern 9).
Command
Parameter
Description
@ AF:
4
<SlotNo.>
Slot13
0
<Grp>
Group1
/
01
<FORMAT>
1080/59.94p
,
D8
<D#>
Pattern 9
Response
Description
AF!40/01,D8
Preset settings are done: SDI output video format of Group1 in Slot13 to
1080/59.94p and Output Delay to 14.83μs.
(2) Performs the set changes.
Command
Description
@ AE:A
Set the preset settings.
Response
Description
AR!W
In preparation.
AR!40/01, D8
Setting preset settings starts.
