9. Maintenance
9.2.3.2 Firmware Update via fos4X Firmware Flasher
Table 49: Material and equipment
Name Type Quantity GTIN
PC
Ethernet connector
(RJ45)
1 -
Ethernet cable RJ45 1 -
Software
fos4X Firmware Flasher
(f3.exe)
1 -
Conditions:
■
Firmware archive for the Blackbird OECD available.
■
IPv6 protocol enabled on the PC.
Doing a firmware update via fos4X Firmware Flasher:
1. Stop the normal operation of the Blackbird OECD.
2. If necessary: Remove the cable from the ETH connector.
3. Connect the PC to the ETH connector.
4. Open the software fos4X Firmware Flasher (f3.exe).
The page FOS4X FIRMWARE FLASHER is displayed.
