Introducing the VM200
12 VM200 User’s Guide
Feature Summary
This section summarizes the main features of the VM200.
Audio Specifications
❑ 20-bit 64-times oversampling, delta sigma modulation A/D con-
verters
❑ 20-bit 128-times oversampling, delta sigma modulation D/A con-
verters
❑ 90dB or higher dynamic range
❑ 20Hz to 20kHz, +1dB/-3dB frequency response
❑ industry standard 44.1K or 48K sampling rates
Inputs and Outputs
❑ 20 Channel Inputs
• Channels 1 - 8: Analog In
• Channels 9-16: ADAT In (20-bit)
• Channels 17-20: Effect Return (for internal effects only)
• Switchable balanced XLR and balanced/unbalanced phone
jacks
• +48V phantom power support for XLR Analog In jacks 1-4
• Route S/P DIF input signals to any of 20 channels
❑ 18 Outputs
• Stereo buss output (ST BUSS OUT)
• Recording buss output (REC BUSS OUT)
• 20-bit digital two-channel output (S/P DIF OUT)
• 20-bit digital ADAT eight-channel output (ADAT OUT)
• Two auxiliary outputs (AUX SEND 1-2)
• ADD AUX function adds two auxiliary outs (AUX SENDS 3-4)
• Solo buss outputs post-fader listen (PFL) signals from any chan-
nel or buss to the Monitor or Phones outputs.
❑ MIDI IN, MIDI OUT, and MIDI THRU (built into the mixer)
❑ Word Clock In and Out
❑ Analog two-track input jacks (2TRK IN) enable you to monitor two
tracks without affecting the mix.
❑ 4 Insert jacks for external effects returns
