Fostex VM200 - Specifications

Specifications
VM200 User’s Guide 203
Specifications
Inputs
Outputs
ANALOG IN
(ch1-ch4)
Connector XLR3-31 (1: Ground, 2: Hot, 3: Cold), 1/4-inch phone jack
A/B switch A: XLR3-31 (mics), B: 1/4-inch phone jack (lines)
Input impedance 3k Ω or higher (mics), 10k Ω or higher (lines)
PAD switch 26dB (+2dB, –1dB)
PHANTOM switch +48V (+1V, –2V)
ANALOG IN
(ch5-ch8)
Connector 1/4-inch phone jack
Input impedance 10k Ω or higher
Nominal input level –10dBV
INSERT IN
(ch1-ch4)
Connector 1/4-inch phone jack
Input impedance 10k Ω or higher
Nominal input level –10dBV
ADAT IN
Connector Optical (Toslink)
Format Adat format
EFFECT RTN
1
(ch17–ch20)
1. Effect returns for the internal effects processor
Connector none
S/P DIF IN
2
2. Assignable to any consecutive odd/even channels
Connector Optical (Toslink)
Format IEC60958 (S/P DIF)
2TRACK IN
Connector RCA pin jack (x2)
Input impedance 10k Ω or higher
Nominal input level –10dBV
WORD IN
Connector BNC
Level TTL/75 Ω (with Terminate ON/OFF switch)
AUX OUT (1, 2)
Connector 1/4-inch phone jack (x2)
Applicable impedance 10k Ω or higher
Nominal output level –10dBV
REC BUSS
OUT
1
(1,2)
Connector 1/4-inch phone jack (x2)
Input impedance 10k Ω or higher
Nominal input level –10dBV
STEREO OUT
(L, R)
Connector 1/4-inch phone jack (x2)
Input impedance 10k Ω or higher
Nominal input level –10dBV
S/P DIF OUT
Connector Optical (Toslink)
Format IEC60958 (S/P DIF)
ADAT OUT
Connector Optical (Toslink)
Format Adat format
MON OUT (L, R)
Connector RCA pin jack (x2)
Applicable impedance 10k Ω or higher
Nominal output level –10dBV
PHONES
Connector 1/4-inch phone jack (x1)
Input impedance 8k Ω or higher
Max. output level 50mW or higher (at 32 Ω )
WORD OUT
Connector BNC
Level TTL/75 Ω
