204 VM200 User’s Guide
General
MIDI Connector DIN 5-pin (x3)
IN/OUT/THRU Format MIDI standards
1. The default setting is REC BUSS. However, with the ADD.AUX parameter turned on, AUX3/4
are available, and these connectors function as AUX OUT 3/4, providing four AUX SENDs.
Frequency response 20Hz–20kHz, +1dB/-3dB (phones: 50Hz–20kHz, +1dB/-3dB)
Dynamic range 90dB or higher (LINE IN CH IN –> ST OUT)
Total harmonic
distortion
CH IN–>ST OUT: 0.08% or less (at 0dBV output)
LINE IN–>ST OUT: 0.008% or less (at 0dBV output)
LINE IN–>PHONES OUT: 0.05% or less (at 50mW/33)
Residual noise
AUX1-4, ST BUSS OUT: -90dB or less (master fader = min, all ch faders = min)
AUX1-4, ST OUT: -78dB or less (master fader = 0dB, all ch faders = 0dB)
MIC->INSERT: –71dBV or less (gain=max, pad=off, Rs=150)
MONITOR OUT (min): –100dBV or less
PHONES (min): -98dBV or less
S/N 1–4CH CH IN (–4dB)–>AUX1-4, ST BUSS OUT: 92dB or higher (IHF-A)
CH IN (–48dB)–>AUX1-4, ST BUSS OUT: 76dB or higher (IHF-A)
5–8CH CH IN (–4dB)–>AUX1-4, ST BUSS OUT: 92dB or higher (IHF-A)
CH IN (–38dB)–>AUX1-4, ST BUSS OUT: 82dB or higher (IHF-A)
Mic gain
1–4CH: 50dB (+3dB -1dB)
5–8CH: 40dB (+3dB -1dB)
Crosstalk 70dB or higher (@ 1kHz), phone: 53dB or higher
PHONES max
output
50mW or higher, impedance 32 Ω , 1kHz
A/D 20bit, 64-times oversampling ∆∑ modulation
D/A 20bit, 128-times oversampling ∆∑ modulation
Fader Motor-driven, 128 steps/60mm
Sampling frequency
Internal: 44.1kHz fixed
External (S/PDIF, ADAT, WORD): 44.1kHz/48kHz+/–6%
Internal processing 32-bit
Equalizer 4-band parametric (LO, LO-MID, HI-MID, HI)
EQ LO
Type: Peaking (bell) or Lo shelving or High Pass Filter
f: 20.3Hz–4.00kHz (1/24 octave/step)
Gain: +/–18dB (0.5dB step)
Q: 0.1–20 (45 steps)
EQ LO-MID
Type: Peaking (bell)
f: 20.3Hz–4.00kHz (1/24 octave steps)
Gain: +/–18dB (0.5dB step)
Q: 0.1–20 (45 steps)
EQ HI-MID
Type: Peaking (bell)
f: 500Hz–20.2kHz (1/24 octave steps)
Gain: +/–18dB (0.5dB step)
Q: 0.1–20 (45 steps)
EQ HI
Type: Peaking (bell) or Lo shelving or High Pass Filter
f: 500Hz–20.2kHz (1/24 octave steps)
Gain: +/–18dB (0.5dB step)
Q: 0.1–20 (45 steps)
Memory
Scene memory: 3 (preset) + 100 (user)
Effect library: 50 (preset) + 50 (user)
EQ library: 50 (preset) + 50 (user)
Display STN graphic LCD (256 x 64 dots)
