Touring the VM200
28
VM200 User’s Guide
Selected EQ Section
An equalizer (EQ) enables you to boost or cut specific frequency
ranges to “shape” a sound.
The VM200 features a four-band parametric equalizer for each input
channel. Each band features rotary controls for Gain, Frequency,
and Q.
The LO-MID and HI-MID bands use parametric EQ. The LO band can
function as an HPF, shelving, or parametric EQ; the HI band can
function as an LPF, shelving, or parametric EQ.
The Selected EQ section features three keys: an
[EQ ON]
key, and
[STORE] and [RECALL] keys for the EQ Library.
For more information on using the EQ, see EQ on page 75.
[EQ ON] Key
The [EQ ON] key enables you to turn on or bypass the equalization
parameters selected via the
[EQ EDIT] keys.
EQ Library
The EQ Library stores sets of equalization parameters as EQ pro-
grams that you can later recall.
The EQ Library features 50 preset EQ programs. You can store up to
50 new EQ programs (in EQ Library locations 50 - 99).
[RECALL] Key
Pressing the [RECALL] key displays the EQ LIBRARY RECALL function
page, which enables you to select from up to 100 equalization pro-
grams (00 - 99).
Use the Data Wheel or [</-1] and [+1/>] keys to scroll through the list,
and press the
[ENTER] key to recall the selected EQ program.
The lower half of the function page displays the pan and fader set-
tings for each channel.
[STORE] Key
The [STORE] key enables you to create and store new EQ programs.
Once you’ve worked on a mix, adjusting the Gain, Frequency, and Q
parameters to your satisfaction for all four bands of each channel,
SELECTED EQ
EQ LIBRARY
STORERECALL
EQ ON
