MIDI In/Out Data Format
VM200 User’s Guide 217
3. FOSTEX EXCLUSIVE MESSAGE
<Reception>
Fostex Exclusive messages are received when [SYSTEM EX. Tx&Rx] is set to ON and the Rx
channel matches the channel of [Dev ID].
When the VM200 receives the System Exclusive message, the specified parameter will be
changed immediately.
When the VM200 receives the Parameter Request message, the corresponding parameter set-
ting will be transmitted immediately.
<Transmission>
Fostex Exclusive messages are transmitted if the Tx channel matches the channel of [Dev ID]
and when you operate the key while [SYSTEM EX. Tx&Rx] is ON.
In response to the Parameter Request messages, VM200 transmits the parameter settings if
the Tx channel matches the channel of [Dev ID].
F0 51 <Device Id>Sub Id> <Data> F7
Command List
Setup Command
Channel/Buss Command
Command Request Status
Master Clock 18,10 <master clock> 28,10 38,10 <master clock>
Fs 18,11 <fs> 28,11 38,11 <fs>
Current Scene Name 18,20 <Name..> 28,20 38,20 <Name..>
Scene Recall 18,22 <SceneNo>
Scene Store 18,23 <SceneNo>
Rcl Safe – Fader 18,28,11 <OnOff> 28,28,11 38,28,11 <OnOff>
Rcl Safe – Pan 18,28,12 <OnOff> 28,28,12 38,28,12 <OnOff>
Rcl Safe – Routing 18,28,30,7f <OnOff> 28,28,30,7f 38,28,30,7f <OnOff>
Rcl Safe – Aux Send Level 18,28,41 <AuxId> <OnOff> 28,28,41 <AuxId> 38,28,41 <AuxId> <OnOff>
Rcl Safe – Eff Send Level 18,28,49 <EffId> <OnOff> 28,28,49 <EffId> 38,28,49 <EffId> <OnOff>
Rcl Safe – Eq On 18,28,50,7f <OnOff> 28,28,50,7f 38,28,50,7f <OnOff>
Rcl Safe – Eq 18,28,5f <OnOff> 28,28,5f 38,28,5f <OnOff>
Eq Enable Ch 18,30 <EqEna> 28,30 38,30 <EqEna>
Add Aux Mode 18,31 <OnOff> 28,31 38,31 <OnOff>
Mon Sel 18,40 <MonSel> 28,40 38,40 <MonSel>
Solo Mode 18,42 <SoloMode> 28,42 38,42 <SoloMode>
Solo Key Mode 18,43 <SoloKeyMode> 28,43 38,43 <SoloKeyMode>
Motor OnOff 18,50 <OnOff> 28,50 38,50 <OnOff>
Power On Recall 18,51 <SceneNo> 28,51 38,51 <SceneNo>
Cascade 18,52 <Cascade> 28,52 38,52 <Cascade>
Memory Backup 18,60 <MemId>
Smoothing 18,32<Mode>f7 28,32,17 38,32<mode>f7
Command Request Status
ST Buss – Ch On 19,01,10 <OnOff> 29,01,10 39,01,10 <OnOff>
ST Buss – Master Fader 19,01,11 <Vol> 29,01,11 39,01,11 <Vol>
ST Buss – Solo 19,01,19 <OnOff> 29,01,19 39,01,19 <OnOff>
REC Buss – Master Level 19,02,11 <Vol> 29,02,11 39,02,11 <Vol>
REC Buss – Solo 19,02,19 <OnOff> 29,02,19 39,02,19 <Vol>
AUX Buss – Ch On 19,05 <AuxId> 10 <OnOff> 29,05 <AuxId> 10 39,05 <AuxId> 10 <OnOff>
AUX Buss – Master Fader 19,05 <AuxId> 11 <Vol> 29,05 <AuxId> 11 39,05 <AuxId> 11 <Vol>
AUX Buss – Solo 19,05 <AuxId> 19 <OnOff> 29,05 <AuxId> 19 39,05 <AuxId> 19 <OnOff>
