MIDI In/Out Data Format
VM200 User’s Guide 219
Command Details
Setup Commands
<< Master Clock>>
command: F0 51 <DevId> 18 10 <MasterClock> F7.
request: F0 51 <DevId> 28 10 F7.
status: F0 51 <DevId> 38 10 <MasterClock> F7.
<MasterClock> 0:int 1:adat 2:spdif 3:word
<< Fs >>
command: F0 51 <DevId> 18 11 <Fs> F7.
request: F0 51 <DevId> 28 11 F7.
status: F0 51 <DevId> 38 11 <Fs> F7.
<Fs> 0:44.1k 1:48k
<< Current Scene Name >>
command: F0 51 <DevId> 18 20 <Name..> F7.
request: F0 51 <DevId> 28 20 F7.
status: F0 51 <DevId> 38 20 <Name..> F7.
<Name..> ASCII Character(max 9byte).
<< Scene Recall>>
command: F0 51 <DevId> 18 22 <SceneNo> F7.
<SceneNo> 00–99:User scene, 100–102:Preset scene.
<< Scene Store >>
command: F0 51 <DevId> 18 23 <SceneNo> F7.
<SceneNo> 00..99: user scene.
<< Rcl Safe – Fader >>
command: F0 51 <DevId> 18 28 11 <OnOff> F7.
request: F0 51 <DevId> 28 28 11 F7.
status: F0 51 <DevId> 38 28 11 <OnOff> F7.
<OnOff> 0:off 1:on.
<< Rcl Safe – Pan >>
command: F0 51 <DevId> 18 28 12 <OnOff> F7.
request: F0 51 <DevId> 28 28 12 F7.
status: F0 51 <DevId> 38 28 12 <OnOff> F7.
<OnOff> 0:off 1:on.
<< Rcl Safe – Routing >>
command: f0 51 <DevId> 18 28 30 7f <OnOff> f7.
request: f0 51 <DevId> 28 28 30 7f f7.
status: f0 51 <DevId> 38 28 30 7f <OnOff> f7.
<OnOff> 0:off 1:on.
<< Rcl Safe – Aux Send Level >>
command:
f0 51 <DevId> 18 28 41 <AuxId> <OnOff> f7.
request: f0 51 <DevId> 28 28 41 <AuxId> f7.
status:
f0 51 <DevId> 38 28 41 <AuxId> <OnOff> f7.
<AuxId> 01:aux1 02:aux2 03:aux3 04:aux4 7f:all_aux
<OnOff> 0:off 1:on.
<< Rcl Safe – Eff Send Level >>
command:
f0 51 <DevId> 18 28 49 <EffId> <OnOff> f7.
request: f0 51 <DevId> 28 28 49 <EffId> f7.
status:
f0 51 <DevId> 38 28 49 <EffId> <OnOff> f7.
<EffId> 01:eff1 02:eff2 7f:all_eff
<OnOff> 0:off 1:on.
<< Rcl Safe – Eq On >>
command: f0 51 <DevId> 18 28 50 7f <OnOff> f7.
request: f0 51 <DevId> 28 28 50 7f f7.
status: f0 51 <DevId> 38 28 50 7f <OnOff> f7.
<OnOff> 0:off 1:on.
<< Rcl Safe – Eq >>
command: f0 51 <DevId> 18 28 5f <OnOff> f7.
request: f0 51 <DevId> 28 28 5f f7.
status: f0 51 <DevId> 38 28 5f <OnOff> f7.
<OnOff> 0:off 1:on.
<< Eq Enable Ch >>
command: f0 51 <DevId> 18 30 <EqEna> f7.
request: f0 51 <DevId> 28 30 f7.
status: f0 51 <DevId> 38 30 <EqEna> f7.
<EqEna> 00:1to8 01:8to16 02:1to16
<< Add Aux Mode >>
command: f0 51 <DevId> 18 31 <OnOff> f7.
request: f0 51 <DevId> 28 31 f7.
status: f0 51 <DevId> 38 31 <OnOff> f7.
<OnOff> 00:off 01:on
<< Smoothing >>
command: f0 51 <DevId> 18 32 <Mode> f7.
request: f0 51 <DevId> 28 32 f7.
status: f0 51 <DevId> 38 32 <Mode> f7
<Mode> 00:Level1 01:Level2
<< Mon Sel >>
command: f0 51 <DevId> 18 40 <MonSel> f7.
request: f0 51 <DevId> 28 40 f7.
status: f0 51 <DevId> 38 40 <MonSel> f7.
<MonSel>
00:ST_BUSS 01:REC_BUSS 02:AUX1 03:AUX2
04:AUX3 05:AUX4 06:EFF1 07:EFF2 08:AUX12
09:AUX34
<< Solo Mode >>
command: f0 51 <DevId> 18 42 <SoloMode> f7.
request: f0 51 <DevId> 28 42 f7.
status: f0 51 <DevId> 38 42 <SoloMode> f7.
<SoloMode>
00:PFL 02:M-SOLO (01:AFL does not apply to
VM200.
)
<< Solo Key Mode >>
command: f0 51 <DevId> 18 43 <SoloKeyMode> f7.
request: f0 51 <DevId> 28 43 f7.
status: f0 51 <DevId> 38 43 <SoloKeyMode> f7.
<SoloKeyMode> 00:latCh 01:unlatCh
<< Motor OnOff >>
command: f0 51 <DevId> 18 50 <OnOff> f7.
request: f0 51 <DevId> 28 50 f7.
status: f0 51 <DevId> 38 50 <OnOff> f7.
<OnOff> 00:off 01:on
