FP PRO PAK'R - Specifications; 4.1 Machine Specification; 4.1.1 General; 4.1.2 Product to be Processed

PRO PAK’R User Manual Version 1.0 Page -26-
FP International
4 specificAtions
4.1 mAchine specificAtion
4.1.1 generAl
Speed: [m/min] Up to 23
Dimensions (length x width x
height): [mm] 350 x 330 x 350
Weight, approx.: [kg] 15
Maximum noise production: [dB(A)] < 70, as measured in the work place
Mains lead length: [m] 5
4.1.2 product to be processed
Contact the manufacturer or distributor for available film configurations exluded wide film kit:
Width: [mm] Max. 460
Core diameter: [mm] 77
Roll diameter: [mm] 280
Weight of roll: [kg] 7.7 – 15
Included wide lm kit (See page 8)
Width: [mm] Max. 750
Core diameter: [mm] 77
Roll diameter: [mm] 280
Weight of roll: [kg] 15.9-19
Recommended lm:
Brand: PRO PAK’R
Distributor: FP International (see “Service Centres” on page 3).
The machine was tested and functioned properly using the appropriate lm.
Caution!
Processing lm other than the recommended types may result
in problems.
4.2 electricAl specificAtion
Supply specication:
Voltage: [V] 230
Amperage fused: [A] 5 Type: Slow-blow
No. of conductors: 3 (1 phase, earth and neutral)
Earthing: required
Frequency: [Hz] 50 - 60
Other requirements: in conformity with EN 60204-1:1995 par 4.3.1.
The machine uses standard mains power
Machine rating:
Rated power: [kW] 0,48
Maximum current: [ A] 2

