Franke F3D3P Service Manual

F3D3 Series Service Manual Customer Level Programming / 1.8
Questions? Call Franke Technical Support Group For Your Area. Page 2 Copyright  2012 Franke, Inc. All rights reserved.
Customer Level Functions
Sub-Menu Functions
Display Values
Notes
Customer Access
Set Language ?
Prev OK Next
Lang = English
Press: OK Change or Exit
Lang = Deutsch
Press: OK Change or Exit
Lang = Espanol
Press: OK Change or Exit
Lang = Francais
Press: OK Change or Exit
Lang = Fr-Eng
Toggles between English-French-English, etc.
Customer Access
Set Temp Cntrl (Control) ?
Prev OK Next
Set Point ?
Yes Exit
SetPt = -05F
Inc Dec OK
-05 F is the default temperature
Press 1 = Inc – To increase one degree, etc
Units ?
Yes Exit
Select Units
Cent Fahr
US default is Fahr [Fahrenheit]
All others default is Cent [Centigrade]
Customer Access
Calibrate ?
Prev OK Next
Calibrate Menu
Begin ?
OK Exit
Calibrate Menu
Load Cell = 0000*
All Clear?
OK Exit
* Two-digit Load Cell TAR (no-load) value. Will
cycle within a narrow range.
Customer Access
Test Motors ?
Prev OK Next
Drum Motor ?
OK Next
Drum Motor
T = 0000
P = 0000
Run Reset Next
T = Motor Torque; P = Peak Torque
Press 1 = Run - To run Drum Motor
Press 2 = Reset - To zero P value
Press 3 = Next - to go to Lift Motor Test
Lift Motor ?
OK Next
Lift Motor
L = 0000
T = 0000
Run Reset Next
L = Live Load Cell value; T = Motor Torque
Press 1 = Run - To run the Lift Motor
Press 2 = Reset - To zero T value
Press 3 = Next - to go to Door Motor Tests
Door Motor ?
OK Next
Door Motor
T = 0000
P = 0000
Run Reset Exit
T = Motor Torque; P = Peak Torque
Press 1 = Run - To run Lift Motor
Press 2 = Reset - To zero P value
Press 3 = Exit - to repeat Motor Tests
Customer Access
View Statistics ?
Prev OK Next
Disp Cyc = 0000000
Cal Cyc = 00000
Next
Reports the number of dispense cycles and
calibration cycles
Small Cyc = 0000000
Medium Cyc = 0000000
Large Cyc = 0000000
Prev Next
Reports the number of Small, Medium and Large
loads dispensed
Drum TQ = 0000 F. TO=0000
Lft TQ = 0000 L. TO=0000
Dor TQ = 0000 D. TO 0000
Prev Next
Reports Drum, Lift and Door Motor over-torque
events; plus fill time-outs (F. TO), lift time-outs (L.
TO) and door time-outs (D. TO)
Zero (Z) = 00000
Large (C) = 00000
Pre (P) = 00000
Prev Exit
Reports Load Cell Calibration values:
Z Default is 40
C Default is 326
P (Pre-Load) Default is 2900
