Installation Manual
2.5 Technical specications
eProWallbox
Description
Recharging Mode Mode 3 - case B
Connector Standard IEC 62196-2 Type2
Connection features Socket with lid and internal shutter
Marking CE, UKCA, TUV, 3A
General Specications
Dimensions [mm] 403x336x190
Weight [kg] ~ 3.8 (without cable)
Protection degree IP55 (IEC 60529)
Impact protection rating IK08 (IEC 62262)
Housing UV resistant plastic
Standard body colour
Black - RAL 9011
White - RAL 9003
Custom body colour
Optional
Custom branding
Optional
Electrical Specications
Power [kW]
Up to 7.4 single-phase
Up to 22 three-phase
Voltage [V/Hz]
230 / 50-60 single-phase
400 / 50-60 three-phase
Current [A] Up to 32
Electrical installation 3P + N + PE, 32A, 400 V / 50-60 Hz P + N + PE, 32 A, 230 V / 50-60 Hz
AC power system TT, TN, IT
Safety and Operation
Operating Temperature range [°C] -25/+50 (without direct exposure to sunlight)
Overheating protection
Humidity Resistance < 95% (non condensing)
Housing re ratings UL94 V-0 | GWFI 960
Overvoltage category OVC III
Residual current monitoring
6 mA DC sensitive RCM device included for DC-leakage
Maximum installation height [m] 2000 a.s.l.
Mounting Wall or optionally on a dedicated pole
Connectivity and Features
RS-485 Modbus RTU
n.2 communication ports
Ethernet
Bluetooth LE 5.0
Wi-Fi
4G / LTE
OCPP 1.6J
User mobile App eSolutions Charging
Installer mobile App
PowerUp
RFID reader
HMI 3.5” TFT touchscreen display
Over-the-air SW upgrade
Energy Meter (built-in)
not MID
Load management (Static and Dynamic)
Static
Dynamic w/ PowerMeter 1 ph (Opt. If requested)
Dynamic w/ PowerMeter 3 ph(Opt. If requested)
ISO 15118
Current phase unbalancing detection
CPMS
