Free2Move eSolutions eProWallbox - Wall mounting

22
Installation Manual
3.5 Wall mounting
CAUTION
The national and international building regulations set out in
IEC 60364-1 and IEC 60364-5-52 must be observed when xing
eProWallbox to the wall. Correct positioning of the charging station
is important to ensure it operates correctly.
Toxthemainbodytothewall,3 plugs (Ø 10x50 mm) are required. The plugs supplied
are universal and are suitable for solid or hollow brick walls. For installation on walls
madeofdierentmaterials(e.g.plasterboard),specicplugsarerequired,andmust
onlybeinstalledoncethemaximumpermissibleloadhasbeenveried.
Before installation, it is necessary to determine the position and distances from walls.
• It is recommended to maintain a distance of 50-60 cm from other walls to
facilitate installation and maintenance.
• It is also recommended to install the wallbox at a height of 130-140cm from
theoor.
• To facilitate installation and wall mounting, use the supplied template to drill
the3xingholes.Thetemplateshouldalsobeusedforlevellingwithaspirit
level.
• Usingadrill,make3xØ10mmholeswherethexingpointsaremarked.
The minimum depth of the holes must be 60 mm. Then remove any drilling
residue from the holes.
