Freenove ESP32 User Manual

Need support?  support@freenove.com
128
Chapter 13 BLE
www.freenove.com █
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
void bleSetup() {
// Create the BLE Device
String s = String("Freenove-Dog");
BLEDevice::init(std::string(s.c_str()));
BLEDevice::setMTU(512);
// Create the BLE Server
pServer = BLEDevice::createServer();
pServer->setCallbacks(new MyServerCallbacks());
// Create the BLE Service
BLEService *pService = pServer->createService(SERVICE_UUID);
// Create a BLE Characteristic
pTxCharacteristic = pService->createCharacteristic(
CHARACTERISTIC_UUID_TX,
BLECharacteristic::PROPERTY_NOTIFY);
pTxCharacteristic->addDescriptor(new BLE2902());
BLECharacteristic *pRxCharacteristic = pService->createCharacteristic(
CHARACTERISTIC_UUID_RX,
BLECharacteristic::PROPERTY_WRITE);
pRxCharacteristic->setCallbacks(new MyCallbacks());
// Start the service
pService->start();
// Start advertising
pServer->getAdvertising()->start();
Serial.println("Bluetooth initialization complete, Waiting a client connection to notify...");
}
void bleStop() {
BLEDevice::deinit();
}
void bleSend(std::string msg) {
if (isBleConnected) {
pTxCharacteristic->setValue(msg);
pTxCharacteristic->notify();
}
}

Freenove ESP32 Specifications

General

Clock Speed	240 MHz
RAM	520 KB SRAM
Wi-Fi	802.11 b/g/n
UART	3
Operating Voltage	3.3V
Input Voltage	5V
DC Current per I/O Pin	40mA
USB	Micro USB
Microcontroller	ESP32
Chip	ESP32
Bluetooth	Bluetooth v4.2 BR/EDR and BLE standard
ADC Channels/Analog Input Pins	18
I2C	Yes
SPI	Yes
Interfaces	I2C, SPI, UART
CPU	Dual-Core 32-bit LX6 Microprocessor
