72
Chapter 3 Fun
ctions of
Freeno
ve App
www.freeno
ve.com
█
Interactio
n Functio
n
1.
Tap the Interact
ion butto
n.
Tip: Tapping the
up an
d down arro
w icon can mak
e t
he robot dog
lie do
wn and unload the se
rvos.
2.
The robot dog c
an do dif
ferent act
ions with
different actio
ns being tapp
ed.
73
75
