60
Chapter 2
Robot Assemb
ly
www.freeno
ve.com
█
Step 9 Assembly
of Calibration Bracket
1.
Assemble the c
alibration b
racket
with two M3*1
2 scre
ws and two M3
nuts.
2.
Insert the calib
ration brack
et into the
robot do
g to suspend the
four le
gs.
61
63
