57
Chapter 2
Robot Assemb
ly
█
www.freeno
ve.com
Step 7 Assembly
of the Cover
1.
Mount the tou
ch sensor to
the cover
with four M1.
4*5 screws.
2.
Use a
3P wire to connect
the touch module
to the robot dog drive
boar
d.
The figure below does not
show the a
crylic part.
