Chapter 2
Robot Assemb
ly
█
www.freeno
ve.com
Step 2 Assembly
of Body Bracket
1.
Mount the belo
w two acryl
ic parts to th
e bottom bo
dy bracke
t with M3*12
screws an
d M3 nut
s.
It should look
as below a
fter assemb
ly.
Pay atten
tion to
the directio
n of the rea
r bo
ard.
Head, mou
nt the
front board he
re
Front board
Rear board
Front board
Rear board
M
3
n
ut
M3*12 scre
w
丝
Rear, mount the
rear board here
Bottom body
bracket
38
