Chapter 2 Robot Assembly
www.freenove.com █
2. Mount four M3*5+8 and four M3*10 brass standoffs to the top body bracket.
3. Mount the board to the top body bracket with four M3*4 screws.
After assembly:
Head
Rear
top
Bottom
Head
Rear
M3*10 brass standoffs
M3*5+8 brass standoffs
M3*4 screws
Rear
Head
Bottom
Top body
bracket
