136
Chapter 14 Camera Web Server
www.freenove.com
18
19
20
21
//#define CAMERA_MODEL_AI_THINKER // Has PSRAM
//#define CAMERA_MODEL_TTGO_T_JOURNAL // No PSRAM
#include "camera_pins.h"
Enter the name and password of the router
23
24
const char *ssid_Router = "********"; //input your wifi name
const char *password_Router = "********"; //input your wifi passwords
Initialize serial port, set baud rate to 115200; open the debug and output function of the serial.
29
30
31
Serial.begin(115200);
Serial.setDebugOutput(true);
Serial.println();
Configure parameters including interface pins of the camera. Note: It is generally not recommended to change
them.
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
camera_config_t config;
config.ledc_channel = LEDC_CHANNEL_0;
config.ledc_timer = LEDC_TIMER_0;
config.pin_d0 = Y2_GPIO_NUM;
config.pin_d1 = Y3_GPIO_NUM;
config.pin_d2 = Y4_GPIO_NUM;
config.pin_d3 = Y5_GPIO_NUM;
config.pin_d4 = Y6_GPIO_NUM;
config.pin_d5 = Y7_GPIO_NUM;
config.pin_d6 = Y8_GPIO_NUM;
config.pin_d7 = Y9_GPIO_NUM;
config.pin_xclk = XCLK_GPIO_NUM;
config.pin_pclk = PCLK_GPIO_NUM;
config.pin_vsync = VSYNC_GPIO_NUM;
config.pin_href = HREF_GPIO_NUM;
config.pin_sccb_sda = SIOD_GPIO_NUM;
config.pin_sccb_scl = SIOC_GPIO_NUM;
config.pin_pwdn = PWDN_GPIO_NUM;
config.pin_reset = RESET_GPIO_NUM;
config.xclk_freq_hz = 20000000;
config.pixel_format = PIXFORMAT_JPEG;
ESP32 connects to the router and prints a successful connection prompt. If it has not been successfully
connected, press the reset key on the ESP32-WROVER.
94
95
96
97
98
99
100
WiFi.begin(ssid, password);
while (WiFi.status() != WL_CONNECTED) {
delay(500);
Serial.print(".");
}
Serial.println("");
Serial.println("WiFi connected");
