46
Chapter 2
Robot Assemb
ly
www.freeno
ve.com
█
6.
Turn ON Bluetoo
th of your
phone
and tap the Con
nect bu
tton on the ap
p.
7.
Selec
t
“
Freenove-Do
g-XXXXXXX
X
”
.
8.
Tap the calibr
ation button
.
Connection
Calibration
47
49
