Chapter 7 Built-in Led
█ www.freenove.com
44
45
46
47
}
lastLedUpdateTime = millis();
}
}
Onboard LED initialization function.
10
11
12
void setupBuiltInLed(){
pinMode(LED_BUILT_IN, OUTPUT);
}
The function that controls the on-board LED to turn on or off.
14
15
16
void setBuiltInLed(bool state){
digitalWrite(LED_BUILT_IN, state);
}
Enter the if statement every occasionally. This usage has the same effect as the delay() function, but it will not
cause the code to be pause.
21
if (millis() - lastLedUpdateTime > intervalTime){
Control the LED's on and off states by shifting a variable, sqValue, and taking the least significant bit as the
control signal.
If the current state of the LED is different from the previous state, control the LED to change its current state
and update the previous state to the current state.
24
25
26
27
28
29
ledStatus = ((sqValue >> bitIndex) & 0x01) ? true : false;
if (ledStatus != lastLedStatus){
digitalWrite(LED_BUILT_IN, (uint8_t)ledStatus);
lastLedStatus = ledStatus;
bitDiff++;
}
Introducing a variable called bitIndex to control the shift amount, so as to change the number of shifts
performed on sqValue each time,. If the number of shifts exceeds 9, the next time entering the if condition
will be delayed by 600ms, and sqValue starts shifting from the 0th bit again.
30
31
32
33
34
35
36
bitIndex++;
if (bitIndex >= 10){
intervalTime = 600;
ledRunnigStatus = 1;
bitDiff = 0;
bitIndex = 0;
}
If the previous shift cycle is completed, set the time for entering the if condition to 100ms each time and
proceed to the next shift cycle.
38
39
40
41
case 1: // off
intervalTime = 100;
ledRunnigStatus = 0;
break;

Freenove ESP32 Specifications

General

Clock Speed	240 MHz
RAM	520 KB SRAM
Wi-Fi	802.11 b/g/n
UART	3
Operating Voltage	3.3V
Input Voltage	5V
DC Current per I/O Pin	40mA
USB	Micro USB
Microcontroller	ESP32
Chip	ESP32
Bluetooth	Bluetooth v4.2 BR/EDR and BLE standard
ADC Channels/Analog Input Pins	18
I2C	Yes
SPI	Yes
Interfaces	I2C, SPI, UART
CPU	Dual-Core 32-bit LX6 Microprocessor
