Outdoor model 24K 36K 48K 60K
Outdoor coil
Number of Rows 2 2 2 2
Tube Pitch(a) in 0.827 0.827 0.827 0.827
Row Pitch(b) in 0.852 0.852 0.852 0.852
Fin Spacing Fins Per in 18 19 17 18
Coil Dimension
(W×H×D)
in
"(35‑5/8+34)×25‑
1/4
×7/8
38‑3/16×31‑
3/8×1‑1
1/16"
38‑3/16×53×1‑
7/16
38‑3/16×53×
1‑11/16
Fin Type
Hydrophilic
aluminium
Hydrophilic
aluminium
Hydrophilic
aluminium
Hydrophilic
aluminium
Tube Outside
Diameter
and Type
mm
Ф7.94,
innergroove
tube
Ф7.94,
innergroove
tube
Ф7.0,
innergroove
tube
Ф7.94,
innergroove
tube
Number of
Circuits
6 5 6 6
Outdoor air flow CFM 1825 2350 3525 3525
Outdoor noise level
(sound pressure) Hi
dB(A) 54 57 59 60
Outdoor Metering Device EEV EEV EEV EEV
Compressor
Model
EATF250D22UMT EATF250D22UMT
EATF400D64UMTA EATF400D64UMTA
Brand GMCC GMCC GMCC GMCC
Compressor
Type Twin ROTARY Twin ROTARY Twin ROTARY Twin ROTARY
Capacity Btu/h 26085 26085 41865 41865
Input W 2080 2080 3385 3385
Rated current
(RLA)
A 9.45 9.45 15.39 15.39
Oil oz VG74 /22.7 VG74 /22.7 VG74 /33.9 VG74 /33.9
Refrigerant
type/Quantity
Type R‑410A R‑410A R‑410A R‑410A
Refrigerant
charge
oz(kg) 70.5(2.0) 98.7(2.8) 142.9(4.05) 142.9(4.05)
Factory
pre‑charge
Ft(m) 25(7.6) 25(7.6) 25(7.6) 25(7.6)
Additional
charge for
each ft
oz/ft 0.38 0.38 0.6 0.6
Outdoor unit
Dimension(W×H×D)
inch
33‑7/8×26‑3/8×
12‑1/4
37‑3/8×33×13‑
3/8
37‑3/8×54‑5/8×
13‑3/8
37‑3/8×54‑5/8×
13‑3/8"
Packing(W×H×D) inch
39×28‑
3/4×17‑3/4
43‑3/4×36‑1/4×
18‑1/8
43‑3/4×60‑1/4×
18‑1/8
43‑3/4×60‑1/4×
18‑1/8
Net weight lbs 112. 4 147.7 227.1 251.3
Shipping Weight lbs 121.3 158.7 253.5 277.5
Design pressure H/L PSIG 550/240 550/240 550/240 550/240
Refrigerant
piping
Liquid side/
Gas side
inch (3/8'/5/8') (3/8'/3/4') (3/8'/7/8') (3/8'/7/8')
Max. pipe length ft 164 246 246 246
Max. difference
in level
ft 98 98 98 98
Operating
temperature
range
Cooling ˚F 5‑122 5‑122 5‑122 5‑122
Heating ˚F ‑13‑75 ‑13‑75 ‑13‑75 ‑13‑75
SPECIFICATIONS
Product Specications (Outdoor Unit )
Figure 201
