Outdoor model 24K 36K 48K 60K
Qty’ per 20’ /40’ /40'HQ
(Outdoor unit)
Set 90/186/186 52/106/106 26/53/53 26/53/53
NOTE:
1. Test conditions:
1.1 Rated capacity test conditions:
Cooling: Indoor: DB 80.0˚F /WB 67.0˚F Outdoor: DB 95.0˚F /WB 75.0˚F
Heating: Indoor: DB 70.0˚F /WB 60.0˚F Outdoor: DB 47˚F /WB 43˚F
1.2 SEER & HSPF test standard: AHRI 210/240.
2. The Sound Pressure Level is based on the following conditions: Outdoor unit.
Measure the noise value of 3 points which are 1 meter in front of the three sides of the unit surface.
(front/left/right) and 1/2 (unit height +1) meter high from floor level, and calculate the weighted average of the noise.
3. The above data was measured in an anechoic chamber. Please take into consideration
the reflected sound of your specific application environment.
4. All specifications are subject to change by the manufacturer without prior notice.
5. Max. Running Current (A): REFER TO NAMEPLATE
6. Follow all National and local codes and regulations when selecting field wires, and all the above are the minimum wire size.
7. When transmitting cable (SI) is longer than 100 feet, a larger wire size should be selected.
8. Install main switch and circuit breaker for each system separately. Select a high response type circuit breaker that acts within
0.1 second.
SPECIFICATIONS
Product Specications (Outdoor Unit)
Figure 201
