12 PB
SPECIFICATIONS
Product Specications (Indoor Unit)
Indoor model 24K 36K 48K 60K
Type US Duct US Duct US Duct US Duct
Power supply V/ph/Hz 208~230/1/60 208~230/1/60 208~230/1/60 208~230/1/60
Moisture
Removal
L/h 2.2 4.5 5.5 7.50
Pts/h 4.64 9.5 11.6 15.80
Min. Ampacity A 3.3 4.8 6.8 6.8
Max. td Fuse/
Breaker
A 10 10 15 15
Nominal Sensitive
Current (mA)
30 30 30 30
Communication
Cable
No. × AWG 5×18 5×18/ 5×18 5×18
Thermostat
Cable
5x18 or 6x18 (when using Matched Air Handler)
Indoor Fan
Motor
(Multi Speed
ECM)
Qty 1 1 1 1
Model ZWK702B006073 ZWK702B500026
ZKSD‑560‑
8‑50‑14
ZKSD‑560‑8‑58
Output HP 1/3 1/2 3/4 3/4
RLA A 2.4~2.6 3.6~3.8 5.0~5.4 5.0~5.4
Speed r/min 350~1400 350~1400 350~1400 350~1400
Indoor Air Flow Rated CFM 800 1120 1588 1706
Indoor Coil
Number of Rows 4 4 5 5
Tube Pitch(a) in 0.827 0.827 0.827 0.827
Row Pitch(b) in 0.535 0.535 0.535 0.535
Fin Spacing Fins Per in 18 18 17 17
Fin Type
Hydrophilic
Aluminium
Hydrophilic
Aluminium
Hydrophilic
Aluminium
Hydrophilic
Aluminium
Tube outside
Diameter
and Type
mm
Ф7, I nnergroove
Tube
Ф7, Innergroove
Tube
Ф7,Innergroove
Tube
Ф7,Innergroove
Tube
Coil mm 2(444× 420×54.4) 2(444×420 ×54.4) 2 (509×546×68) 2 (509×546×68)
Dimension
(W×H×D)
in
2(17‑1/2×16‑1/2×
2‑1/8)
2(17‑1/2×16‑
1/2×2‑1
/8)
2 (20×21‑1/2×2‑
11/16)
2 (20×21‑1/2×2‑
11/16)
Number of
Circuits
8 8 12 12
ESP
Rated In. W.C. 0.18 0.228 0.276 0.276
Range In. W.C. 0‑0.8 0‑0.8 0‑0.8 0‑0.8
Indoor Noise Level (Hi) dB(A) 55 57 64 65
Throttle Type TXV TXV TXV TXV
Dimension
(W×H×D)
inch
19‑5/8 × 46‑
1/8 × 21‑5/8
19‑5/8 × 46‑
1/8 × 21‑5/8
22×53 ‑7/8×24 22×53 ‑7/8×24
Packing
(W×H×D)
inch
22‑1/2×49‑5/8×
25‑3/8
22‑1/2×49‑5/8×
25‑3/8
25‑1/4×55‑1/2×28 25‑1/4×55‑1/2×28
Net Weight lbs 135.5 140 187.2 187.2
Shipping Weight lbs 158.6 163.1 214 214
Drainage Water Pipe Diameter inch 3/4'' 3/4'' 3/4'' 3/4''
"Design
Pressure"
H/L PSIG 550/240 550/240 550/240 550/240
Figure 202
