5.CAPACITIES AND SELECTION DATA
Airflow
(CMF)
Outdoor
DB(°F)
IWB (°F) 59 63 67 71
IDB (°F) 70 75 80 85 70 75 80 85 70 75 80 85 70 75 80 85
750
5
TC
16.0 16.1 16.5 16.7 16.5 16.7 16.9 17.0 17.7 17.8 17.9 18.0 \ 21.1 21.3 21.6
S/T
0.99 1.00 1.00 1.00 0.61 0.83 1.00 1.00 0.39 0.57 0.73 0.90 \ 0.39 0.53 0.67
kW
0.98 0.99 1.00 1.00 1.00 1.02 1.03 1.03 1.03 1.04 1.06 1.07 \ 1.25 1.26 1.19
30
TC
16.7 16.9 17.2 17.4 17.2 17.4 17.6 17.8 18.4 18.6 18.7 18.8 \ 22.1 22.2 22.6
S/T
0.99 1.00 1.00 1.00 0.61 0.83 1.00 1.00 0.39 0.57 0.73 0.90 \ 0.39 0.53 0.67
kW
1.09 1.10 1.11 1.11 1.11 1.13 1.14 1.15 1.15 1.16 1.18 1.19 \ 1.39 1.40 1.33
65
TC
17.5 17.7 18.1 18.3 18.1 18.3 18.5 18.7 19.4 19.6 19.7 19.8 \ 23.2 23.4 23.7
S/T
0.99 1.00 1.00 1.00 0.64 0.88 1.00 1.00 0.39 0.59 0.78 0.99 \ 0.38 0.55 0.71
kW
1.21 1.23 1.24 1.24 1.24 1.25 1.27 1.28 1.28 1.29 1.31 1.32 \ 1.54 1.55 1.47
75
TC
17.6 17.8 18.2 18.4 18.2 18.4 18.6 18.8 19.5 19.6 19.8 19.9 \ 23.8 23.9 23.9
S/T
0.99 1.00 1.00 1.00 0.63 0.88 1.00 1.00 0.39 0.59 0.78 1.00 \ 0.38 0.55 0.71
kW
1.25 1.26 1.28 1.28 1.28 1.29 1.30 1.32 1.32 1.33 1.34 1.36 \ 1.70 1.70 1.70
85
TC
17.2 17.4 17.8 18.0 17.8 18.0 18.2 18.4 19.1 19.2 19.4 19.5 \ 22.4 22.5 22.7
S/T
0.99 1.00 1.00 1.00 0.64 0.89 1.00 1.00 0.39 0.59 0.79 1.00 \ 0.39 0.56 0.73
kW
1.41 1.42 1.44 1.44 1.44 1.46 1.47 1.48 1.49 1.50 1.51 1.53 \ 1.81 1.83 1.84
95
TC
16.8 17.0 17.3 17.5 17.3 17.5 17.7 17.9 18.6 18.7 18.8 19.0 \ 21.3 21.4 21.4
S/T
1.00 1.00 1.00 1.00 0.64 0.90 1.00 1.00 0.39 0.60 0.80 1.00 \ 0.39 0.57 0.75
kW
1.66 1.67 1.69 1.69 1.69 1.71 1.73 1.74 1.76 1.77 1.78 1.79 \ 2.05 2.05 2.05
105
TC
16.3 16.5 16.9 17.1 16.9 17.1 17.2 17.4 18.1 18.2 18.3 18.5 \ 19.5 19.6 19.5
S/T
1.00 1.00 1.00 1.00 0.65 0.90 1.00 1.00 0.39 0.60 0.81 1.00 \ 0.39 0.59 0.79
kW
1.93 1.95 1.97 1.97 1.97 2.00 2.01 2.04 2.05 2.07 2.08 2.09 \ 2.15 2.16 2.13
115
TC
13.0 13.1 13.5 13.6 13.5 13.6 13.8 13.9 14.5 14.6 14.6 14.7 \ 15.5 15.6 15.7
S/T
1.00 1.00 1.00 1.00 0.66 1.00 1.00 1.00 0.40 0.66 0.93 1.00 \ 0.40 0.65 0.90
kW
1.71 1.73 1.75 1.75 1.75 1.77 1.78 1.80 1.82 1.83 1.84 1.85 \ 1.91 1.91 1.92
122
●
TC
11.1 11.2 11.4 11.6 11.4 11.6 11.7 11.8 12.3 12.4 12.4 12.5 \ 13.2 13.3 13.3
S/T
1.00 1.00 1.00 1.00 0.62 0.85 1.00 1.00 0.40 0.60 0.79 0.99 \ 0.39 0.58 0.76
kW
1.76 1.78 1.80 1.80 1.80 1.82 1.84 1.86 1.88 1.89 1.90 1.90 \ 1.96 1.97 1.97
Performance data (Heating operation at rated frequency)
60K outdoor unit matches 60K indoor unit
Airflow ID OD
75 65 55 47 35 25 15 5 -4 -13
1500
60
TC 66.0 66.0 65.8 63.2 53.7 50.0 44.9 38.9 34.0 25.5
kW 4.34 4.63 5.45 5.93 5.51 5.89 5.57 5.27 5.01 4.01
70
TC 51.0 50.7 50.9 50.2 50.2 49.1 44.3 38.3 33.3 25.0
kW 3.24 3.42 4.02 4.69 5.63 6.40 6.03 5.67 5.35 4.28
75
TC 43.0 42.8 42.8 42.8 42.2 42.2 42.0 35.9 30.4 22.8
kW 2.70 2.90 3.38 4.00 4.65 5.45 6.28 5.91 5.57 4.46
80
TC 35.2 35.2 35.2 35.1 34.9 34.6 34.6 34.6 29.9 22.4
kW 2.25 2.39 2.80 3.26 3.88 4.38 5.09 5.99 5.81 4.65
1700
60
TC 73.7 73.7 71.6 64.0 54.6 50.9 45.9 39.7 34.6 26.0
kW 5.13 5.43 6.03 5.81 5.45 5.85 5.55 5.27 5.03 4.02
70
TC 57.1 56.8 56.3 56.0 53.3 49.7 45.4 38.8 33.8 25.4
kW 3.74 4.00 4.59 5.29 5.95 6.32 5.99 5.67 5.39 4.31
75
TC 48.1 48.0 48.0 47.1 47.3 47.3 42.6 36.4 30.9 23.2
kW 3.14 3.34 3.92 4.45 5.33 6.26 6.24 5.89 5.59 4.47
80
TC 39.4 39.4 39.4 39.3 38.8 38.6 38.8 35.9 30.4 22.8
kW 2.59 2.74 3.20 3.70 4.32 5.01 5.81 6.15 5.81 4.65
1900
60
TC 82.1 80.8 72.9 65.2 55.4 51.7 46.5 40.4 35.2 26.4
kW 6.03 6.17 5.99 5.81 5.49 5.89 5.63 5.37 5.15 4.12
70
TC 63.1 62.9 62.9 62.8 54.1 50.5 45.7 39.6 34.4 25.8
kW 4.30 4.57 5.37 6.24 5.97 6.36 6.05 5.77 5.51 4.41
75
TC 53.7 53.6 52.9 52.8 52.8 49.9 43.4 37.0 31.7 23.8
kW 3.66 3.88 4.41 5.17 6.15 6.64 6.30 5.99 5.71 4.57
80
TC 44.3 44.1 44.1 43.9 43.3 43.3 42.8 36.5 31.1 23.3
kW 3.04 3.22 3.70 4.32 4.99 5.79 6.56 6.22 5.91 4.73
25
(CFM)
(°F)
(°F)
