P1.11
Xmmc0DATA0
P1.12
Xmmc2DATA0
P1.13
Xmmc0DATA1
P1.14
Xmmc2DATA1
P1.15
Xmmc0DATA2
P1.16
Xmmc2DATA2
P1.17
Xmmc0DATA3
P1.18
Xmmc2DATA3
P1.19
Xmmc0CDn
P1.20
Xmmc2CDn
P1.21
XEINT16/KP_COL0
P1.22
XEINT24/KP_ROW0
P1.23
XEINT17/KP_COL1
P1.24
XEINT25/KP_ROW1
P1.25
XEINT18/KP_COL2
P1.26
XEINT26/KP_ROW2
P1.27
XEINT19/KP_COL3
P1.28
XEINT27/KP_ROW3
P1.29
XEINT10
P1.30
XEINT14
P1.31
XEINT11
P1.32
XEINT15
P1.33
XpwmTOUT0
P1.34
Xi2cSCL0
P1.35
XpwmTOUT1
P1.36
Xi2cSDA0
P1.37
XuhDM
P1.38
Xi2cSCL2
P1.39
XuhDP
P1.40
Xi2cSDA2
P1.41
VD0(Blue LSB)
P1.42
VD1
P1.43
VD2
P1.44
VD3
P1.45
VD4
P1.46
VD5
P1.47
VD6
P1.48
VD7(Blue MSB)
P1.49
VD8(Green LSB)
P1.50
VD9
P1.51
VD10
P1.52
VD11
P1.53
VD12
P1.54
VD13
P1.55
VD14
P1.56
VD15(Green MSB)
P1.57
VD16(Red LSB)
P1.58
VD17
P1.59
VD18
P1.60
VD19
P1.61
VD20
P1.62
VD21
P1.63
VD22
P1.64
VD23(Red MSB)
P1.65
Vertical Synchronous Signal
P1.66
Horizontal Synchronous Signal
P1.67
RGB Data Sampling Clock
P1.68
RGB Data Enable
P1.69
GND
P1.70
Boot Mode Select
P2
Spec
P2
Spec
P2.1
XuTXD0
P2.2
XuRXD0
P2.3
XuTXD1
P2.4
XuRXD1
P2.5
XuTXD2
P2.6
XuRXD2
P2.7
XuTXD3
P2.8
XuRXD3
P2.9
XuCTSn1
P2.10
XuRTSn1
P2.11
CAM_A_D0
P2.12
CAM_A_D1
P2.13
CAM_A_D2
P2.14
CAM_A_D3
P2.15
CAM_A_D4
P2.16
CAM_A_D5
