P2.17
CAM_A_D6
P2.18
CAM_A_D7
P2.19
CAM_A_PCLK
P2.20
CAM_A_VSYNC
P2.21
CAM_A_HREF
P2.22
CAM_A_FIELD
P2.23
CAM_A_CLKenb
P2.24
XhdmiTX1P
P2.25
XhdmiTX0P
P2.26
XhdmiTX1N
P2.27
XhdmiTX0N
P2.28
XhdmiTXCP
P2.29
XhdmiTX2P
P2.30
XhdmiTXCN
P2.31
XhdmiTX2N
P2.32
XEINT13/HDMI_HPD
P2.33
Xi2cSDA1
P2.34
Xi2cSCL1
P2.35
XuoID
P2.36
XspiCS0
P2.37
XuoDM
P2.38
XspiMISO0
P2.39
XuoDP
P2.40
XspiMOSI0
P2.41
XuoVBUS
P2.42
XspiCLK0
P2.43
XmipiMDPCLK
P2.44
XuoDRVVBUS
P2.45
XmipiMDNCLK
P2.46
GND
P2.47
XmipiMDP0
P2.48
Ethernet PHY RX-
P2.49
XmipiMDN0
P2.50
Ethernet PHY RX+
P2.51
XmipiMDP1
P2.52
Ethernet PHY TD-
P2.53
XmipiMDN1
P2.54
Ethernet PHY TD+
P2.55
XmipiMDP2
P2.56
Ethernet Link / Active LED
P2.57
XmipiMDN2
P2.58
Ethernet Speed LED
P2.59
XmipiMDP3
P2.60
GND
P2.61
XmipiMDN3
P2.62
Head Phone Detect
P2.63
Head Phone Output R
P2.64
Head Phone Output L
P2.65
SPK_OUT_LP
P2.66
SPK_OUT_LN
P2.67
SPK_OUT_RP
P2.68
SPK_OUT_RN
P2.69
Mic Input P
P2.70
Mic Input N
P3
Spec
P3
Spec
P3.1
5VDC Input
P3.2
GND
P3.3
XEINT0
P3.4
XEINT1
P3.5
XEINT2
P3.6
XEINT3
P3.7
XEINT4
P3.8
XEINT5
P3.9
XEINT6
P3.10
XEINT8
P3.11
Xm0ADDR0
P3.12
Xm0ADDR1
P3.13
Xm0ADDR2
P3.14
NC
P3.15
Xm0CSn0
P3.16
XnRSTOUT(System Reset Output)
P3.17
Xm0WEn
P3.18
Xm0OEn
P3.19
Xm0DATA0
P3.20
Xm0DATA1
P3.21
Xm0DATA2
P3.22
Xm0DATA3
