Select the system according to the table above, and set on the controls.
When the system has been selected, the display changes to the system
parameters.
The number of the following parameters depends on the system
selected:
System 0 … ←
←←
←
Bypass pump available
Yes, if there is a bypass pump for return feed lift
No, if a Thermovar valve or a mixer is used for the return
feed lift.
System 1 … X
Storage temp. mid. av.
You can insert a sensor into the storage mid to optimise
the storage layering.
:
DHW control available
Yes, if DHW is available.
No, for hot water heat exchanger.
System 15 …
Oil boiler blocking off No locks the oil boiler when using a common chimney.
Switch value
Oil boiler switch valve: separates the oil boiler
hydraulically from the storage tank.
DHW priority
All heating circuits are switched off during DHW tank
loading.
Solar element
For controlling the temperature difference of a solar panel
system with element. This is carried out via heating
circuit control 1 or 3 (mixer heating circuit 1 or 3 is not
possible).
Heating circuit 1,2,3,4
No, if the heating circuit control is used for “solar
element”.
Remote control 1,2,3,4
A remote control is available as an option for each
heating circuit. If you are using a console RBG 3100 also
set parameter to “yes”.
7.4.4 Checks before first heating up
Heating system
Check that there is sufficient water in the heating system.
Page 35, Checking the system pressure
Check that the heating system is completely vented
Check if the relevant safety devices are available and working
correctly
Page 13, 2.4 Safety Devices
Check that there is sufficient air supply and venting
Page 10, 2.3.3 Ventilating the Boiler Room
