Installers and service technicians
Parameter list - Lambdatronic P 3100
Fröling Heizkessel- und Behälterbau Ges.m.b.H, Industriestraße 12, A-4710 Grieskirchen, Austria Page 75
Tel +43 (0) 7248 606-0 Fax +43 (0) 7248 606-600 info@froeling.com www.froeling.com
B0190806
7.5.4 Manual operation menu
Used for manual fuel feed to the burner and manual operation of heat
exchanger motor and ash screw.
MANUAL FUEL ON←
←←
←
Manual fuel feed to burner
ASH SCREW OFF←
←←
←
Ash screw ON/OFF
EOS OFF←
←←
←
Heat exchanger cleaning ON/OFF
FILLING OFF←
←←
←
After activating the parameter, the container is filled
with fuel, regardless of fill level, until the function is
turned off or the switch point of the level sensors is
reached. When the level sensor reaches its limit
value, the fill level value is set to 100%.
Caution: Parameter only for universal suction
systems Uno/Eco/Komfort and bag silo units!
7.5.5 Manual digi.menu OUT
Used to test the digital outputs and is intended only for heating
engineers. The display depends on the configuration.
HC1 pump A 0←
←←
←
Heating circuit 2-4 same, if present
HC1-Mi open A 0←
←←
←
Heating circuit 2-4 same, if present
HC1-Mi closed A 0←
←←
←
Heating circuit 2-4 same, if present
Oil boiler
contact A 0←
←←
←
Burner relay: for burner start or burner release
Only present if system with oil burner has been
selected.
HC0 pump A 0←
←←
←
Only possible if system does not have oil burner.
Lambd Heat 0 A 0←
←←
←
Lambda probe heating
Ignition A 0←
←←
←
Ignition fan
Suction A 0←
←←
←
Only with suction discharge unit!
Ash screw A 0←
←←
←
Ash screw
Relays for
Fault message A 0←
←←
←
Fault message relays for external warning device
(e.g.: buzzer, house control system)
Heat exchanger
motor A 0←
←←
←
Heat exchanger cleaning
Switch power
supply A 0←
←←
←
Only with universal suction system; Servomotor
supply system
Probe 1
Active A 0←
←←
←
Only with universal suction system; control probe 1
Probe 2
Active A 0←
←←
←
Only with universal suction system; control probe 2
Probe 3
Active A 0←
←←
←
Only with universal suction system; control probe 3
A 0... Automatic, OFF A... AUTOMATIC
A 1... Automatic, OFF 0... Manual OFF
1... Manual ON
