1 P2 Pellet Boiler with heat-exchanger
2a Stoker assembly for screw discharge
2b Stoker assembly for suction unit discharge
3 Key switch to lock screw outputs of the pellet module (only for screw discharge)
4 Additional insulating door for reduced heat radiation
5 Combustion chamber door with viewing window
6 Ashcan with wheels and handle (ash screw module)
7 Ash drawer, front and rear (ash drawer module); no illustration
8 Heat-exchange system: Turbulator with automatic heat exchanger cleaning mechanism
9 Pellets lock with two chamber system as protection against blowback
10 Stoker screw for introducing fuel with drive motor
11 Ignition fan with automatic ignition
12 Upper part of gravity shaft to secure fuel for secure fuel delivery (only for direct screw discharge)
o.A. For suction systems: cyclone container with suction motor (attached directly at the pellet lock)
13 Main switch: switches the system on and off
14 HZG 0 / ÖL (Auto/Manual/Off)
15 HEATING 1-4 (Auto/Manual/Off)
16 PUMP 1-3 (Auto/Manual/Off)
17 BLOWER FAN (Auto/Manual/Off)
18 Lambdatronic P 3100 control system with two-row display for showing operating status
19 The corresponding LED illuminates when there is activity from positions 14-17
20 Status LED (Operating Status): - slow, green flashing light: Boiler activated
- fast green flashing light: Boiler deactivated
- red flashing light: Fault
21 Start key: Switch on boiler
22 Stop key: Switch off boiler
23 Back key: Return from a submenu or undo an entry
24 Up arrow key: Move the arrow up in the menu, increase or activate parameters
25 Down arrow key: Move the arrow down in the menu, decrease or deactivate parameters
26 Enter key: Go to submenus, call up or confirm entries
