Fronius AB Profinet RT - Application Example

AB Profinet IRT FO
(2)
(5)
(3) (4)
(1)
)5()1(
(1) Blanking cover
(2) LocalNet connection
for connecting the interconnecting
hosepack
(3) LocalNet connection
for connecting other system com-
ponents
(4) LocalNet connection
for connecting other system com-
ponents
(5) Ethernet SCRJ-MM-C connec-
tion
for connecting the Profinet data
cable
Application
example
(1)
(2)
(3)
(4)
(5)
(6) (7)
(8)
(9)
(10)
(1) Power source
(2) Cooling unit
(3) AB Profinet
(4) Interconnecting hosepack
(5) Profinet data cable
(6) Robot control
(7) Welding wire drum
(8) Robot
(9) Welding torch
(10) Wirefeeder
