© FRONIUS 2013 34
4080-4260
4080-4180 4074 4190 38 2134-0,5*Dp
4500*Vw/Dp 4160-4260 4154 4270 2174-0,5*Dp
4260-4440
4260-4360 4254 4370 40 2224-0,5*Dp
4680*Vw/Dp 4340-4440 4334 4450 2264-0,5*Dp
4440-4620
4440-4540 4434 4550 41 2314-0,5*Dp
4860*Vw/Dp 4520-4620 4514 4630 2354-0,5*Dp
4620-4800
4620-4720 4613 4729 43 2404-0,5*Dp
5040*Vw/Dp 4700-4800 4693 4809 2444-0,5*Dp
4800-4980
4800-4900 4793 4909 45 2494-0,5*Dp
5220*Vw/Dp 4880-4980 4873 4989 2534-0,5*Dp
4980-5160
4980-5080 4973 5089 45 2594-0,5*Dp
5400*Vw/Dp 5060-5160 5053 5169 2624-0,5*Dp
5160-5340
5160-5260 5153 5269 48 2674-0,5*Dp
5580*Vw/Dp 5240-5340 5233 5349 2714-0,5*Dp
5340-5520
5340-5440 5333 5449 48 2764-0,5*Dp
5760*Vw/Dp 5420-5520 5413 5529 2808-0,5*Dp
5520-5700
5520-5620 5513 5629 50 2854-0,5*Dp
5940*Vw/Dp 5600-5700 5593 5709 2894-0,5*Dp
5700-5880
5700-5800 5693 5809 51 2944-0,5*Dp
6120*Vw/Dp 5780-5880 5773 5889 2984-0,5*Dp
5880-6060
5880-5980 5873 5989 53 3034-0,5*Dp
6300*Vw/Dp 5960-6060 5953 6069 3074-0,5*Dp
Configuration of flexible segments
Dp[mm]
Number
of rail
L=1884
Number of
rail
L=1695,6
Number of
rail
L=1130,4
1 1560-1740 - 3 1
2 1740-1920 3 - 1
3 1920-2100 3 1 -
4 2100-2280 3 - 2
5 2280-2460 - 5 -
6 2460-2640 3 2 -
7 2640-2820 - 5 1
8 2820-3000 - 6 -
9 3000-3180 3 3 -
10 3180-3360 6 - -
11 3360-3540 - 7 -
12 3540-3720 6 - 1
13 3720-3900 6 1 -
14 3900-4080 6 - 2
15 4080-4260- 6 1 1
16 4260-4440 6 2 -
17 4440-4620 6 1 2
18 4620-4800 6 2 1
19 4800-4980 6 3 -
20 4980-5160 9 - -
21 5160-5340 6 3 1
22 5340-5520 9 - 1
23 5520-5700 9 1 -
24 5700-5880 9 - 2
25 5880-6060 9 1 1
