27
EN
Use the "Up/Down" keys to set the
cross-section of the charging lead.
Confirm with the "Pause/Start" key.
The charger is configured with the correct
charging lead cross-section as per the or-
der.
An incorrectly set charging lead cross-sec-
tion can have a negative influence on the
charging process.
If the displayed charging configuration
is correct, confirm the charging confi-
guration with the “Pause/Start” key.
The charger is preconfigured as specified in
the order.
If the charger was ordered without any additional configuration, the following default set-
tings are used:
- Type of battery: Pb-wet (for PzS, GiS)
- Characteristic: 6 - RI
- Maximum number of cells intended for the charger
- Charging time: 7 - 8 h
If the configuration does not coincide with the battery used, the parameters need to be ad-
justed accordingly.
More information on the charger parameters can be found under "Configuration mode" in
the "Display" chapter.
Charging
WARNING!
Danger due to escaping battery acid or explosion if faulty batteries are charged.
This can result in serious injury and damage to property.
► Before charging, ensure that the battery to be charged is fully functional.
WARNING!
Danger due to the use of the incorrect type of battery and incorrect charge settings.
This can result in serious injury and damage to property.
► Before starting the charging process, make sure that the correct type of battery is set
on the charger.
► The following settings must be performed for the individual types of batteries before
charging:
Charging curve
Nominal voltage (number of battery cells)
Battery capacity (Ah) or charging time (h)
More information on the charger parameters can be found under "Configuration mode" in
the "Display" chapter.
