Download
- The data relating to the logged charging parameters stored in the device's datalogger
is saved to the USB flash drive for the I-SPoT VIEWER.
- Additionally, events as well as the device settings and user curves (configuration) are
saved.
- The following time ranges can be selected for the datalogger:
1 month
3 months
Everything
Since last time
Download optional
The following options are available:
- I-SPoT VIEWER
The logged data is saved in the same way as for the "Download" function, but saving
only the I-SPoT VIEWER data.
- Save datalogger
The logged data is saved in the same way as for the "Download" function, but is saved
as “csv” files rather than in the I-SPoT VIEWER format.
(Automatically created folder structure for the “.csv” files”: *
Fronius\<device serial number>\Charges\<yyyymmdd>\<hhmmss.csv>)
- Save events.
Events are saved to the USB flash drive.
- Save configuration.
The device settings are saved to the USB flash drive.
Load configuration
- Loads a suitable device configuration stored on the USB flash drive on the device.
Load dealer text
- A text file can be loaded from the USB flash drive that is displayed as soon as the de-
vice enters an error state.
- The text file can, for example, contain the contact details of the dealer.
- The file must be saved on the USB flash drive as a ".txt" file in "unicode" format.
- The file name must be "dealer.txt".
- The number of characters is restricted to 99.
* If a USB flash drive is connected while charging is in progress, the csv files are
saved directly to the USB flash drive. In this case, the folder structure is also cre-
ated automatically and differs due to the presence of the "Datalog" folder instead
of the "Charges" folder.
Status codes
If a fault occurs during operation, specific status codes may be displayed. Faults can result
from the following:
- Battery fault
- The voltage of the connected battery is unsuitable.
- The device has overheated.
- There is a software or hardware fault.
